JET GH-1880ZX Long-Bed Large Spindle Bore Geared Head Lathe

The JET GH-1880ZX lathe combines heavy-duty industrial construction, powerful geared headstock operation, and extended turning capacity for demanding metalworking applications. Designed for professional machine shops, fabrication facilities, industrial maintenance departments, and heavy repair operations, this 18″ x 80″ metal lathe provides the power and rigidity required for turning, facing, boring, drilling, threading, grooving, and general machining operations.

Powered by a 10 HP, 230V three-phase motor, the GH-1880ZX delivers the cutting power needed for machining larger workpieces and demanding materials. Its geared headstock provides 12 selectable spindle speeds ranging from 26 to 1,500 RPM, allowing operators to choose appropriate cutting speeds for different materials, tooling, and machining requirements.

With an 18″ swing over the bed and an actual 83.5″ distance between centers, the machine accommodates long industrial workpieces such as shafts, rollers, hydraulic components, threaded rods, and precision-machined replacement parts. Its extended bed provides additional machining capacity compared with shorter models in the GH-ZX series.

The GH-1880ZX also offers a 25.6″ swing through the gap, providing additional clearance for short, larger-diameter workpieces when the removable gap section is properly configured.

One of the machine’s standout features is its 3-1/8″ spindle bore, which allows larger-diameter bar stock to pass through the headstock. This through-spindle capacity can help reduce material handling, unnecessary cutoffs, and repeated workpiece repositioning.

The JET GH-1880ZX lathe features a D1-8 camlock spindle mount, MT7 spindle taper, MT5 spindle taper with sleeve, and MT4 tailstock taper for compatibility with appropriately sized chucks, centers, and industrial workholding equipment.

Its rigid one-piece cast iron base helps dampen vibration and resist machine deflection during heavy cutting operations, supporting dimensional consistency and surface finish quality across longer workpieces.

Key Features and Benefits

• 10 HP Three-Phase Motor: Provides substantial power for heavy-duty turning, facing, boring, drilling, and threading applications.
• 12-Speed Geared Headstock: Offers selectable spindle speeds from 26 to 1,500 RPM.
• 18″ Swing Over Bed: Accommodates larger-diameter cylindrical workpieces.
• Long-Bed Design: Provides an actual 83.5″ distance between centers for machining longer industrial components.
• Large 3-1/8″ Spindle Bore: Allows larger-diameter bar stock to pass through the headstock.
• D1-8 Camlock Spindle Mount: Provides a robust mounting interface for compatible chucks and industrial workholding equipment.
• MT7 Spindle Taper: Supports compatible spindle tooling and accessories.
• MT5 Spindle Taper with Sleeve: Provides additional tooling compatibility when the appropriate sleeve is used.
• MT4 Tailstock Taper: Accepts compatible centers, drill chucks, and other tooling.
• 25.6″ Swing Through Gap: Provides additional clearance for short, larger-diameter workpieces.
• 45 Inch Thread Selections: Supports inch threading from 2 to 72 TPI.
• 39 Metric Thread Selections: Provides metric threading from 0.2 to 14 mm.
• 40 Longitudinal and 40 Cross Feed Selections: Offers flexibility for different machining and finishing operations.
• Rigid One-Piece Cast Iron Base: Helps reduce vibration and machine flex during heavy-duty cutting.
• Integrated Coolant System: Supports tool cooling and lubrication during machining.
• Electronic Chuck Key Holder: Helps reduce the risk of unsafe startup with a chuck key left in place.
• Foot Brake: Provides an operator-accessible spindle stopping control.
• Chuck Guard: Provides a protective barrier at the workholding area.
• Full-Length Splash Guard: Helps contain machining chips and coolant.
• Protective Leadscrew Cover: Helps protect the leadscrew from chips and debris.
• UL 987 Certification: Meets the manufacturer’s stated electrical safety certification.
• Pre-Shipment Inspection: JET inspects each machine before shipment.
• Two-Year Parts and Labor Warranty: Provides manufacturer-backed coverage subject to JET’s warranty terms.

Heavy-Duty 18 x 80 Metal Lathe for Industrial Applications

This 18 x 80 metal lathe provides the extended turning capacity, large spindle bore, and rigid construction required for professional machining operations. The 18 x 80 metal lathe is particularly well suited for machining long shafts, industrial rollers, hydraulic components, structural rods, fabrication parts, and precision-turned replacement components.

Available Lathe Accessories

We carry a wide selection of metal lathe accessories, including chucks, cutting tools, toolholders, centers, drill chucks, steady rests, and additional workholding equipment.

Digital readout systems (DROs), collet closers, taper attachments, and other accessories may be available depending on machine configuration and compatibility.

Accessories are configuration-dependent. JET does not offer every accessory combination as a factory-configured machine. Please contact us with your preferred accessories so we can verify availability and pricing.

Contact us for JET GH-1880ZX lathe availability, accessories, and pricing.
