JET GHB-1236 Geared Head Metal Lathe

The JET GHB-1236 lathe combines geared headstock performance, durable machine construction, and versatile machining capabilities in a compact industrial metalworking lathe. Designed for machine shops, maintenance departments, fabrication facilities, and general metalworking applications, this 12″ x 36″ metal lathe provides dependable performance for turning, facing, boring, drilling, threading, and precision repair work.

Powered by a 2 HP, 230V single-phase motor, the GHB-1236 provides machining capability without requiring three-phase electrical service. Its geared headstock offers nine selectable spindle speeds ranging from 75 to 1,400 RPM, allowing operators to select appropriate cutting speeds for different materials, tooling, and machining operations.

With a 12″ swing over the bed and 33″ distance between centers, the GHB-1236 accommodates a variety of cylindrical workpieces, including shafts, bushings, pins, threaded components, and replacement parts. Its 18″ swing through the gap provides additional clearance for short, larger-diameter workpieces when the removable gap section is properly configured.

The machine’s 1-9/16″ spindle bore allows compatible bar stock to pass through the headstock, reducing the need for unnecessary material cutoffs and repositioning. A D1-4 camlock spindle mount supports compatible chucks and workholding accessories.

JET incorporates Meehanite headstock castings to provide structural rigidity and vibration-damping characteristics during machining. The machine also includes a four-way tool post and a tailstock with an MT3 taper for compatible centers, drill chucks, and other tooling.

The GHB-1236 supports both inch and metric threading, with 36 inch thread selections ranging from 4 to 60 TPI and 32 metric thread selections ranging from 0.4 to 7 mm.

Key Features and Benefits

• 2 HP Single-Phase Motor: Operates on 230V single-phase power, making it suitable for shops without three-phase electrical service.
• Nine-Speed Geared Headstock: Offers spindle speeds from 75 to 1,400 RPM for a range of machining operations.
• 12″ Swing Over Bed: Accommodates cylindrical workpieces up to the machine’s specified swing capacity.
• 33″ Distance Between Centers: Supports machining of shafts, rods, and other longer components.
• 1-9/16″ Spindle Bore: Allows compatible bar stock to pass through the headstock.
• D1-4 Camlock Spindle Mount: Supports compatible chucks and workholding equipment.
• Meehanite Headstock Castings: Provide structural rigidity and help dampen machining vibration.
• 18″ Swing Through Gap: Provides additional clearance for short, larger-diameter workpieces.
• MT5 Spindle Taper: Supports compatible spindle tooling.
• MT3 Spindle Taper with Sleeve: Offers additional tooling compatibility with the appropriate sleeve.
• MT3 Tailstock Taper: Accepts compatible centers, drill chucks, and other tooling.
• Four-Way Tool Post: Allows multiple cutting tools to be mounted for convenient tool changes.
• 36 Inch Thread Selections: Supports inch threading from 4 to 60 TPI.
• 32 Metric Thread Selections: Provides metric threading from 0.4 to 7 mm.
• 48 Longitudinal Feed Selections: Provides feed-rate flexibility for different turning operations.
• 36 Cross Feed Selections: Supports controlled cross-feed machining.
• 7-1/8″ Bed Width: Provides a stable foundation for the carriage and tailstock.
• Adjustable Tailstock Offset: Supports appropriate taper-turning setups.
• Two-Year Manufacturer Warranty: Provides manufacturer-backed coverage subject to JET’s warranty terms.

Versatile 12 x 36 Metal Lathe for Machine Shops and Maintenance Departments

This 12 x 36 metal lathe offers a combination of compact machine size, geared headstock performance, and threading versatility for professional machining and repair work.

The 12 x 36 metal lathe is particularly well suited for machining shafts, bushings, pins, threaded components, prototypes, and industrial replacement parts.

Available Lathe Accessories

We carry a wide selection of metal lathe accessories, including cutting tools, toolholders, chucks, centers, drill chucks, steady rests, and additional workholding equipment.

Digital readout systems (DROs) and other compatible accessories may be available depending on machine configuration.

Accessories are configuration-dependent. JET does not offer every accessory combination as a factory-configured machine. Please contact us with your preferred accessories so we can verify availability and pricing.

Contact us for JET GHB-1236 lathe availability, accessories, and pricing.
