JET JVM-836 Step Pulley Vertical Milling Machine

The JET JVM-836 milling machine delivers professional machining capabilities in a compact vertical knee mill design. Built for toolrooms, repair facilities, maintenance departments, and smaller metalworking shops, the JVM-836 combines a rigid machine structure, precision-ground components, and straightforward mechanical controls for dependable milling, drilling, and boring operations.

Powered by a 1-1/2 HP motor, the JVM-836 is available in two electrical configurations. The JVM-836-1 operates on 115/230V single-phase power, while the JVM-836-3 operates on 230V three-phase power. Both models use a step pulley drive system that allows operators to select spindle speeds appropriate for different cutting tools and materials.

The precision-ground 7-7/8″ x 35-3/4″ worktable, commonly described as an 8″ x 36″ table, provides room for machine vises, fixtures, and workpieces without requiring the floor space of a larger industrial knee mill. With up to 24″ of longitudinal travel, 9-1/2″ of cross travel, and 14″ of knee travel, the machine offers versatility for a variety of machining setups.

The JET JVM-836 milling machine features an R-8 spindle taper that accommodates commonly available milling collets, end mill holders, and cutting tools. Its 5″ spindle travel, manual fine-feed control, and micrometer depth adjustment allow operators to perform controlled drilling, boring, and milling operations.

Precision-ground dovetail ways, a chromed quill, high-precision spindle bearings, and a one-shot lubrication system contribute to the machine’s accuracy, durability, and ease of maintenance.

Key Features and Benefits

• 1-1/2 HP Motor: Provides power for general-purpose milling, drilling, and boring operations.
• Compact 8″ x 36″ Class Worktable: Offers a practical working surface for smaller machine shops and maintenance facilities.
• Step Pulley Spindle Drive: Provides selectable spindle speeds for different cutting materials and tooling.
• Single-Phase and Three-Phase Models: Allows selection based on available shop electrical service.
• R-8 Spindle Taper: Accepts widely available milling collets, toolholders, and cutting accessories.
• 5″ Spindle Travel: Provides working range for drilling and boring applications.
• Up to 24″ Longitudinal Table Travel: Accommodates a variety of workpiece lengths.
• 9-1/2″ Cross Table Travel: Provides flexibility when positioning workpieces and cutting tools.
• 14″ Knee Travel: Allows vertical adjustment for different machining setups.
• Precision-Bored and Honed Milling Head: Supports accurate spindle alignment and consistent operation.
• Chromed Quill: Provides a durable spindle-feed surface.
• High-Precision Spindle Bearings: Support smooth spindle rotation during machining.
• Precision-Ground Dovetail Ways: Provide controlled movement of the machine table and knee.
• One-Shot Lubrication System: Simplifies lubrication of the ways and leadscrews.
• Adjustable Milling Head: Tilts 90° left or right for angled machining applications.
• Manual Fine Feed and Depth Adjustment: Provides additional control for drilling and boring operations.

Available Electrical Configurations

JVM-836-1 – Single-Phase Model

The JVM-836-1 features a 1-1/2 HP, 115/230V single-phase motor, factory-wired for 115V operation. It provides five spindle speeds ranging from 240 to 1,550 RPM, making it suitable for shops without three-phase electrical service.

JVM-836-3 – Three-Phase Model

The JVM-836-3 features a 1-1/2 HP, 230V three-phase motor with ten spindle speeds ranging from 120 to 1,550 RPM. This configuration provides additional speed selections for different machining requirements.

Available Milling Machine Accessories

We carry a wide selection of milling machine accessories, including collet sets, machine vises, clamping kits, drill chucks, and coolant systems.

Digital readout systems (DROs), table power feeds, and other milling accessories may also be available separately, depending on compatibility and availability.

Accessories are configuration-dependent. JET does not offer every accessory combination as a factory-configured machine. Please contact us with your preferred accessories so we can verify availability and pricing.

Contact us for JET JVM-836 milling machine availability, accessories, and pricing.
